Tranny fitment...
#1
Driver
Thread Starter
iTrader: (1)
Join Date: Feb 2010
Location: FL
Posts: 172
Likes: 0
Received 0 Likes
on
0 Posts
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
I have a 1JZ SC300 with a 5 spd and was thinking about swapping it for a 6 spd supra tranny. Will that tranny fit on the 1JZ motor? What will I need to make it work or will it even be worth my time and money? Just pondering on something different.
#2
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
nice avatar! Yes it will work, but it's not jut a tranny swap if you want to go V160, you need to change a few things along with it. If you're just asking about whether it will bolt on to your engine, the answer is yes, will that be it for the swap, no.
#3
Lexus Champion
iTrader: (2)
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
What 5spd are running? If you have an R154 in there I wouldn't swap it out. In order to make the Getrag fit you need to modify the transmission tunnel along with changing your driveshaft and swapping out the rear end to one with the proper gearing. All in all with all the parts you'd be looking at around 4K to do a 6spd swap.
#4
Instructor
iTrader: (1)
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
What 5spd are running? If you have an R154 in there I wouldn't swap it out. In order to make the Getrag fit you need to modify the transmission tunnel along with changing your driveshaft and swapping out the rear end to one with the proper gearing. All in all with all the parts you'd be looking at around 4K to do a 6spd swap.
Trending Topics
#10
Driver
Thread Starter
iTrader: (1)
Join Date: Feb 2010
Location: FL
Posts: 172
Likes: 0
Received 0 Likes
on
0 Posts
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
well idk what the tranny is currently in it. how do i find out which one it is?
ClearP nice avatar to you too buddy.
i understand how it would be easier to do the 2jzgte 6 spd swap rather than the tranny swap for the 1jz.
thanks for the help guys
ClearP nice avatar to you too buddy.
i understand how it would be easier to do the 2jzgte 6 spd swap rather than the tranny swap for the 1jz.
thanks for the help guys
#13
Lexus Test Driver
iTrader: (44)
Join Date: Jan 2007
Location: Maryland /Germantown
Posts: 5,139
Likes: 0
Received 7 Likes
on
7 Posts
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
Get under the car if you have 2 inspection plates, left and right of the Bellhousing!! and then if you see where the slave cylinder pushes on the fork W/O removing the inspection plates.
The V160 will bolt right up to the 1JZ and you don't have to touch the tunel for clearance.
You will need a custum DS, you can do the whole swap for ~5K if you do the labor yourself.
I would just sell the 1JZ swap and hopefully you have an R154 behind it, and get the full 2JZ GTE V160 swap.
If you are going for Big power down the road get the V160 then Transmission will be the last thing to worry about, if you have the money get the V160.
The V160 will bolt right up to the 1JZ and you don't have to touch the tunel for clearance.
You will need a custum DS, you can do the whole swap for ~5K if you do the labor yourself.
I would just sell the 1JZ swap and hopefully you have an R154 behind it, and get the full 2JZ GTE V160 swap.
If you are going for Big power down the road get the V160 then Transmission will be the last thing to worry about, if you have the money get the V160.
#15
Lexus Champion
iTrader: (2)
![Default](https://www.clublexus.com/forums/images/icons/icon1.gif)
The W58 might as well have been made out of paper. Some guys have no issues with it in the 350-400HP range. While others blow them up. They key to longevity on a W58 would be to not bang on it like some guys do. The R154 is a stronger motor and has been known to hold upwards of 700 HP.
