Well - mabye here are some electrical profs around which can decode and/or comment the wirings below: (HEADLIGHT BEAM LEVEL CONTROL ACTUATOR)

SC OLD WIRING

SC NEW WIRING

regartus maximus
marcus

p.s. 4PIN CON#: 90980-10931

powmax

OLD Headlight Disassemble Instructions

NEW LEVEL MOTOR DISASSEMBLING ILLU.



Have a closer look at the Level-Motor - it can be turned out... soooooo maybe the new one could be replaced by the old... "@GAMMALEX" - let's try!!!

regards
marcus

hipendicul

You may be able to swap the motors but as far as just wiring up the new motor to the old controller, I would advise against it. The old motor has what looks like two leads for the motor (+) and (-) and three wires for the sensor (G), (T), and (E), where as the new motor has only four wires (+) and (-) for the motor and I'm guessing (+) and (-) for the sensor.

I would just set the lights to a set position and then just wire up the old motor and leave it dangling somewhere to get the light off.

talwang

iTrader: (4)

you guys should try hipendicul's method as well.
I am never an expert in that kind of stuff.

GammaLex

You cant swap the motors. I ended up doing what Ken said plugging in the old motors and pull tie it in place to leave the system in loop so the light on the dash stays off. I hope its just a temp fix untill I can get the right parts from Japan.If i had my aero and 20" id take some more pics

powmax

@GammLex

does the old HID Bulb(D2S) fit also the new socket (D4S)???

regards
marcus

GammaLex

no you need the new d4s bulbs

powmax

oki doki - than i've to order a pair... headlights should arrive tomorrow 2gether with TOM's Front - jau jau jau!!!

kind regards
marcus

GammaLex

What are you doing to keep the auto leveling working. Once you have the lights on you wont even worry about them anymore lol

talwang

iTrader: (4)

don't forget that 06 grill if you have ordered Tom's 06 front.

GammaLex

you will also need new plugs for the wedge bulbs and turn signals aswell if your new lights didnt come with them.

powmax

Thanks GAMMA and TALWANG...

yes - everythings on order...
Turnsignal must be the same connector... Clearancelight is different on both sides...

FRONT has arrived today and is now in the paint shop...

regards
marcus

GammaLex

The turn signal from your old headlights wont screw into your new headlights

powmax

The Part No#s are the same, checked this again today... maybe euro headlights are slightly different... - we will see... get you up2date!
